ImageMosaic configuration¶

Primary configuration file¶

The mosaic configuration file is the primary file used to store the configuration parameters that control the ImageMosaic plugin. When created by GeoServer it is by default called <directory>.properties, where <directory> is the name of the root directory of the store. (It is not related to the store name in GeoServer.) It can have other names, as long as it does not conflict with other files such as datastore.properties or indexer.properties. This file usually does not require manual editing.

The table below describes the various elements in this configuration file.

A sample configuration file follows:

Levels=0.4,0.4
Heterogeneous=false
AbsolutePath=false
Name=osm
TypeName=osm
Caching=false
ExpandToRGB=false
LocationAttribute=location
SuggestedSPI=it.geosolutions.imageioimpl.plugins.tiff.TIFFImageReaderSpi
CheckAuxiliaryMetadata=false
LevelsNum=1

datastore.properties¶

By default the ImageMosaic index is specified by a shapefile, which is located at the root of the ImageMosaic directory, just like the primary configuration file.

If needed, different storage can be used for the index — like a spatial DBMS, which is the preferred solution when you wish to share the ImageMosaic itself in a cluster of GeoServer instances. In this case the user must supply GeoServer with the proper connection parameters, which can be specified by using a datastore.properties file placed at the root of the ImageMosaic directory.

Here is a sample datastore.properties file for a PostGIS index:

SPI=org.geotools.data.postgis.PostgisNGDataStoreFactory
host=localhost
port=5432
database=osm
schema=public
user=user
passwd=password
Loose\ bbox=true
Estimated\ extends=false
validate\ connections=true
Connection\ timeout=10
preparedStatements=true

Here is a sample datastore.properties file for a PostGIS index via JNDI:

SPI=org.geotools.data.postgis.PostgisNGJNDIDataStoreFactory
#String
# JNDI data source
# Default "java:comp/env/"+"jdbc/mydatabase"
jndiReferenceName=

#Boolean
# perform only primary filter on bbox
# Default Boolean.TRUE
Loose\ bbox=true

#Boolean
# use prepared statements
#Default Boolean.FALSE
preparedStatements=false

indexer.properties¶

In addition to the required envelope and location attributes, the schema for the index store may expose other custom attributes which can be used later for filtering the ImageMosaic granules on the fly during a WMS or WCS request or to diver WMS and WCS dimensions like TIME, ELEVATION and so on. This is configured by the indexer.properties file:

Here is a sample indexer.properties file:

Schema=*the_geom:Polygon,location:String,ingestion:java.util.Date,elevation:Double
PropertyCollectors=TimestampFileNameExtractorSPI[timeregex](ingestion),DoubleFileNameExtractorSPI[elevationregex](elevation)
TimeAttribute=ingestion
ElevationAttribute=elevation
Caching=false
AbsolutePath=false

An example of optional CoverageNameCollectorSPI could be:

CoverageNameCollectorSPI=org.geotools.gce.imagemosaic.namecollector.FileNameRegexNameCollectorSPI:regex=^([a-zA-Z0-9]+)

This defines a regex-based name collector which extracts the coverage name from the prefix of the file name, so that an ImageMosaic with temperature_2015.tif, temperature_2016.tif, pressure_2015.tif, pressure_2016.tif will put temperature* granules on a temperature coverage and pressure* granules on a pressure coverage.

Other properties files¶

The PropertyCollectors parameter in the example above indicates two additional .properties files used to populate the ingestion and elevation attributes:

timeregex.properties:

regex=[0-9]{8}T[0-9]{9}Z(\?!.\*[0-9]{8}T[0-9]{9}Z.\*)

The above is a property file containing a regex used to extract Date and Time represented in ISO-8601 as part of the filename. (Note the T char between digits for date and digits for time, as per ISO-8601)

In case of custom format datetimes in filename, an additional format element should be added after the regex, preceded by a comma, defining the custom representation.

regex=.*([0-9]{10}).*,format=yyyyMMddHH

elevationregex.properties:

regex=(?<=_)(\\d{4}\\.\\d{3})(?=_)
