Hibernate Spatial 3 + PostGIS9 搭配实现

<?xml version='1.0' encoding='UTF-8'?>
<!DOCTYPE hibernate-configuration PUBLIC
          "-//Hibernate/Hibernate Configuration DTD 3.0//EN"
          "http://hibernate.sourceforge.net/hibernate-configuration-3.0.dtd">

<!-- Generated by MyEclipse Hibernate Tools.                   -->
<hibernate-configuration>

    <session-factory>
        <property name="dialect">org.hibernatespatial.postgis.PostgisDialect</property>
        <property name="connection.url">jdbc:postgresql://localhost:5432/postgis</property>
        <property name="connection.username">username</property>
        <property name="connection.password">password</property>
        <property name="connection.driver_class">org.postgresql.Driver</property>

    	<property name="show_sql">true</property>
    	<!--
    	<property name="hibernate.hbm2ddl.auto">create</property>
    	 -->
    	<mapping class="test.Student"/>

    </session-factory>

</hibernate-configuration>

3：HibernatePostgisSessionFactory.java

package test;

import org.hibernate.HibernateException;
import org.hibernate.Session;
import org.hibernate.cfg.Configuration;
import org.hibernate.cfg.AnnotationConfiguration;

/**
 * Configures and provides access to Hibernate sessions, tied to the
 * current thread of execution.  Follows the Thread Local Session
 * pattern, see {@link http://hibernate.org/42.html }.
 */
public class HibernatePostgisSessionFactory {

    /**
     * Location of hibernate.cfg.xml file.
     * Location should be on the classpath as Hibernate uses
     * #resourceAsStream style lookup for its configuration file.
     * The default classpath location of the hibernate config file is
     * in the default package. Use #setConfigFile() to update
     * the location of the configuration file for the current session.
     */
    private static String CONFIG_FILE_LOCATION = "/hibernate.postgis.cfg.xml";
	private static final ThreadLocal<Session> threadLocal = new ThreadLocal<Session>();
    private  static Configuration configuration = new AnnotationConfiguration();
    private static org.hibernate.SessionFactory sessionFactory;
    private static String configFile = CONFIG_FILE_LOCATION;

	static {
    	try {
			configuration.configure(configFile);
			sessionFactory = configuration.buildSessionFactory();
		} catch (Exception e) {
			System.err
					.println("%%%% Error Creating SessionFactory %%%%");
			e.printStackTrace();
		}
    }
    private HibernatePostgisSessionFactory() {
    }

	/**
     * Returns the ThreadLocal Session instance.  Lazy initialize
     * the <code>SessionFactory</code> if needed.
     *
     *  @return Session
     *  @throws HibernateException
     */
    public static Session getSession() throws HibernateException {
        Session session = (Session) threadLocal.get();

		if (session == null || !session.isOpen()) {
			if (sessionFactory == null) {
				rebuildSessionFactory();
			}
			session = (sessionFactory != null) ? sessionFactory.openSession()
					: null;
			threadLocal.set(session);
		}

        return session;
    }

	/**
     *  Rebuild hibernate session factory
     *
     */
	public static void rebuildSessionFactory() {
		try {
			configuration.configure(configFile);
			sessionFactory = configuration.buildSessionFactory();
		} catch (Exception e) {
			System.err
					.println("%%%% Error Creating SessionFactory %%%%");
			e.printStackTrace();
		}
	}

	/**
     *  Close the single hibernate session instance.
     *
     *  @throws HibernateException
     */
    public static void closeSession() throws HibernateException {
        Session session = (Session) threadLocal.get();
        threadLocal.set(null);

        if (session != null) {
            session.close();
        }
    }

	/**
     *  return session factory
     *
     */
	public static org.hibernate.SessionFactory getSessionFactory() {
		return sessionFactory;
	}

	/**
     *  return session factory
     *
     *	session factory will be rebuilded in the next call
     */
	public static void setConfigFile(String configFile) {
		HibernatePostgisSessionFactory.configFile = configFile;
		sessionFactory = null;
	}

	/**
     *  return hibernate configuration
     *
     */
	public static Configuration getConfiguration() {
		return configuration;
	}

}

4：Student.java

package test;

import javax.persistence.Entity;
import javax.persistence.GeneratedValue;
import javax.persistence.Id;

import org.hibernate.annotations.GenericGenerator;
import org.hibernate.annotations.Type;

import com.vividsolutions.jts.geom.Polygon;

@Entity
public class Student {
	@Id
	@GeneratedValue(generator="increment")
    @GenericGenerator(name="increment", strategy = "increment")
	private int id;
	private String name;

	@Type(type="org.hibernatespatial.GeometryUserType")
    private Polygon location;

	public int getId() {
		return id;
	}
	public void setId(int id) {
		this.id = id;
	}
	public String getName() {
		return name;
	}
	public void setName(String name) {
		this.name = name;
	}

	public Polygon getLocation() {
		return location;
	}
	public void setLocation(Polygon location) {
		this.location = location;
	}
}

package test;

import org.hibernate.Session;
import org.junit.After;
import org.junit.Before;
import org.junit.Test;

import com.vividsolutions.jts.geom.Geometry;
import com.vividsolutions.jts.geom.Point;
import com.vividsolutions.jts.geom.Polygon;
import com.vividsolutions.jts.io.ParseException;
import com.vividsolutions.jts.io.WKTReader;


public class TestHibernatePostGIS {

	Session session;

	@Before
	public void init(){
		session = HibernatePostgisSessionFactory.getSession();
	}
	@Test
	public void save() {
		session.beginTransaction();
		Student s = new Student();
		s.setName("xx");
		Geometry geom = wktToGeometry("POLYGON((1 1,20 1,20 20,1 20,1 1))");

		s.setLocation((Polygon)geom);
		session.save(s);
		session.getTransaction().commit();
	}

	private Geometry wktToGeometry(String wktPoint) {
        WKTReader fromText = new WKTReader();
        Geometry geom = null;
        try {
            geom = fromText.read(wktPoint);
        } catch (ParseException e) {
            throw new RuntimeException("Not a WKT string:" + wktPoint);
        }
        return geom;
    }

	public Point createPoint(String lon,String lat){
		String wktPoint = "POINT(10 5)";
		WKTReader fromText = new WKTReader();
        Geometry geom = null;
        try {
            geom = fromText.read(wktPoint);
        } catch (ParseException e) {
            throw new RuntimeException("Not a WKT string:" + wktPoint);
        }
        if (!geom.getGeometryType().equals("Point")) {
            throw new RuntimeException("Geometry must be a point. Got a " + geom.getGeometryType());
        }
        return (Point)geom;
    }

	@After
	public void destory(){
		HibernatePostgisSessionFactory.closeSession();
	}
}
